JK-BD6A8S10P Smart BMS 100A with 0.6A Active Balancer 4S-8S
Category: BMS
1 / 8
Product Description
The JK-BD6A8S10P Smart BMS is a high-performance Battery Management System designed for 4S to 8S lithium battery packs. It is suitable for LiFePO4, Lithium-Ion and LTO battery chemistries, making it a versatile solution for 12V and 24V battery systems.
With a powerful 0.6A Active Balancing System, the JK-BD6A8S10P actively transfers energy between cells to help maintain better cell voltage consistency. This improves battery pack performance and helps maximize usable battery capacity.
The BMS supports up to 100A continuous charging and discharging current, with a maximum instantaneous current rating of up to 200A. It also provides multiple battery protection functions including overcharge, over-discharge, over-current, short-circuit and temperature protection.
The integrated Bluetooth communication allows users to monitor battery information through a compatible mobile application, while display support provides convenient access to important battery parameters.
The JK-BD6A8S10P is an excellent choice for LiFePO4 battery packs, solar energy storage, inverter batteries, RVs, electric vehicles, electric bikes, mobility applications and other high-capacity lithium battery systems.
Product Highlights
JK-BD6A8S10P Smart BMS
4S–8S Battery Configuration
100A Continuous Charge Current
100A Continuous Discharge Current
200A Maximum Instantaneous Current
0.6A Active Cell Balancing
Supports LiFePO4, Lithium-Ion & LTO
Bluetooth Smart Monitoring
Display Support
Overcharge & Over-Discharge Protection
Over-Current Protection
Short-Circuit Protection
Temperature Protection
Coulomb Counter / Battery Capacity Monitoring
Common-Port Charging & Discharging
Designed for high-capacity lithium battery packs
Key Features
0.6A Active Cell Balancing
The JK-BD6A8S10P uses active balancing technology to transfer energy between battery cells instead of simply dissipating excess energy as heat. This helps maintain better cell voltage consistency and improves overall battery pack efficiency.
100A Continuous Current
With up to 100A continuous charging and discharging capability, this BMS is suitable for demanding lithium battery applications where reliable current handling is required.
4S–8S Battery Support
The BMS supports 4S to 8S battery configurations, making it suitable for different lithium battery pack designs. For LiFePO4 applications, this commonly covers 12.8V (4S) and 25.6V (8S) nominal battery configurations.
Multi-Chemistry Support
The JK-BD6A8S10P can be configured for different lithium battery chemistries, including:
LiFePO4
Lithium-Ion
LTO
Bluetooth Smart Monitoring
The built-in Bluetooth function allows compatible smartphones to monitor important battery parameters through the JK BMS application, including cell voltages, total battery voltage, current and protection status.
Comprehensive Battery Protection
The BMS continuously monitors the battery pack and provides protection against abnormal operating conditions such as:
Overcharge
Over-discharge
Over-current
Short circuit
Over-temperature
Abnormal cell voltage
Display Support
The BMS supports a compatible display for convenient monitoring of battery information and system status.
Technical Specifications
Specification Details
- Brand JK / Jikong
- Model JK-BD6A8S10P
- BMS Type Smart Active Balancing BMS
- Battery Chemistry LiFePO4 / Lithium-Ion / LTO
- Battery Series 4S–8S
- LiFePO4 Configuration 4S–8S
- Lithium-Ion Configuration 4S–8S*
- LTO Configuration 6S–8S*
- Continuous Charge Current 100A
- Continuous Discharge Current 100A
- Maximum Instantaneous Current 200A
- Active Balancing Current 0.6A
- Balancing Type Active Energy Transfer
- Communication Bluetooth
- Display Support Yes
- Charging & Discharging Port Common Port
- Short-Circuit Protection Yes
- Over-Current Protection Yes
- Overcharge Protection Yes
- Over-Discharge Protection Yes
- Temperature Protection Yes
- Coulomb Counter Yes
- Cell Voltage Monitoring Yes
- Mobile App Compatible JK BMS App
- Operating Temperature Approx. -30°C to 70°C
- Supply Voltage 7.5–36V
- Maximum Cell Monitoring 8 Cells
- Application Lithium Battery Pack Management
Suitable Applications
The JK-BD6A8S10P can be used in a wide range of lithium battery applications, including:
12V LiFePO4 Batteries
24V LiFePO4 Batteries
Solar Energy Storage Systems
Inverter Battery Packs
RV & Camper Battery Systems
Electric Bikes
Electric Vehicles
Mobility Scooters
Marine Battery Systems
Backup Power Systems
Off-Grid Energy Storage
DIY Lithium Battery Packs
High-Capacity Energy Storage Applications
Why Choose JK-BD6A8S10P?
The JK-BD6A8S10P combines high-current battery protection, active cell balancing and smart Bluetooth monitoring in one compact BMS.
Its 0.6A active balancing helps improve cell consistency, while the 100A continuous current capability makes it suitable for high-power battery applications. Bluetooth monitoring gives users convenient access to battery information and protection parameters.
For customers building a reliable 12V or 24V LiFePO4 battery, this JK Smart BMS provides an advanced solution for battery protection and cell management.
Important Compatibility Note
Before purchasing or installing the BMS, confirm:
Battery chemistry
Number of cells in series
Maximum charging current
Maximum continuous load current
Battery cell voltage range
Required communication interface
Available installation space
For best performance, the battery cells should be properly matched and the BMS should be configured according to the selected cell chemistry.
